Feature node Displays all parameters that make up the part feature.

All part occurrences experience changes to part parameters.

Part node Displays parameters for all features that make up the part.

For a subassembly, exposes only parameters for that assembly, and not its child parts.

Assembly node Exposes only assembly parameters at the node level.

Right-click a feature node to evaluate parametrically, and click Show Parameters.

In the browser, expand the model nodes to reveal the features in a part.

Later, identify that parameter in a simulation, and explore the effect of thickness changes.

Evaluate only a few of the parameters that describe a part feature so that the result of the simulation remains geometrically predictable.Įxample: To evaluate the effect of various material thicknesses, create a parameter called matl_thickness.
